Elbows
Elbows are installed between two lengths of pipe or tube to allow for a change in the direction of the process line — typically at 90° or 45° angles.
We work to ensure all angles are exact and all tube, bend, and tee connections are uniform. Elbows from Stainless Products meet 3-A sanitary standards and are manufactured from 304/316L stainless steel and finished off with a 32RA ID and OD polish. Other finishes available upon request.
Connections available: butt weld, tri-clamp, I Line, Bevel Seat, and John Perry.
Sanitary Weld Elbows
90° Butt Weld Elbow - SP2S
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.06 | 2.94 | 4.06 | 5.31 | 6.31 | 8.31 |
| B (in) | 1.00 | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
90° 15 x Butt Weld Elbow - SP2T
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.94 | 4.06 | 5.19 | 6.31 | 8.31 |
| B (in) | 3.66 | 4.78 | 6.03 | 7.22 | 9.53 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
90° Clamp x Butt Weld - SP2CW
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.94 | 4.06 | 5.19 | 6.31 | 8.31 |
| B (in) | 3.44 | 4.56 | 5.69 | 6.81 | 8.94 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
90° 13H-14 x Butt Weld Elbow - SP2F
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.94 | 4.06 | 5.19 | 6.31 | 8.31 |
| B (in) | 3.66 | 4.78 | 6.03 | 7.22 | 9.53 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
45° Butt Weld Elbow - SP2KS
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 1.19 | 1.63 | 2.31 | 3.00 | 3.69 | 4.81 |
| B (in) | 1.00 | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
45° 15 x Butt Weld Elbow - SP2KT
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.34 | 3.03 | 3.84 | 4.59 | 6.03 |
| B (in) | 1.63 | 2.31 | 3.00 | 3.69 | 4.87 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
45° 13H-14 x Butt Weld Elbow - SP2KP
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.34 | 3.03 | 3.84 | 4.59 | 6.03 |
| B (in) | 1.63 | 2.31 | 3.00 | 3.69 | 4.81 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
45° Clamp x Butt Weld Elbow - SP2KCW
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.13 | 2.81 | 3.50 | 4.19 | 5.44 |
| B (in) | 1.63 | 2.31 | 3.00 | 3.69 | 4.81 |
| C (in) | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 |
Sanitary Clamp Elbows
90° Clamp End Elbow - SP2C
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 | 6 |
|---|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.75 | 3.50 | 4.25 | 5.00 | 6.63 | 9.69 |
| R (in) | 1.50 | 2.25 | 3.00 | 3.75 | 4.50 | 6.00 | 9.00 |
90° Custom Angle Elbow (Made to Order) - SP2CCAE
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 |
|---|---|---|---|---|
| R (in) | 2.25 | 3.00 | 3.75 | 4.50 |
90° Both Ends Clamp Elbow - SP2C-31
Dimensional Data
| Size | 2 x 1 | 2 x 1.5 | 2.5 x 2 | 3 x 2 | 3 x 2.5 | 4 x 3 |
|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.75 | 3.50 | 3.50 | 4.25 | 5.13 |
| B (in) | 2.00 | 2.75 | 3.50 | 3.50 | 4.25 | 5.00 |
90° Large End Clamp/Small End 13H-14 Elbow - SP2E-31
Dimensional Data
| Size | 2 x 1 | 2 x 1.5 | 2.5 x 2 | 3 x 2 | 3 x 2.5 | 4 x 3 |
|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.75 | 3.50 | 3.50 | 4.25 | 5.13 |
| B (in) | 2.19 | 2.97 | 3.72 | 3.72 | 4.60 | 5.41 |
90° One End Clamp/Other End 13H-14 Elbow - SP2F-14
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.75 | 3.50 | 4.25 | 5.00 | 6.63 |
| B (in) | 2.67 | 3.72 | 4.60 | 5.41 | 7.03 |
90° One End 15/Other End Clamp Elbow - SP2F-15
Dimensional Data
| Size | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|
| A (in) | 2.75 | 3.50 | 4.25 | 5.00 | 6.63 |
| B (in) | 2.97 | 3.72 | 4.60 | 5.41 | 7.03 |
90° Large End 14/Other End Clamp Elbow - SP2F-31
Dimensional Data
| Size | 2 x 1 | 2 x 1.5 | 2.5 x 2 | 3 x 2 | 3 x 2.5 | 4 x 3 |
|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.75 | 3.50 | 3.50 | 4.25 | 5.00 |
| B (in) | 2.25 | 3.00 | 3.78 | 3.84 | 4.59 | 5.53 |
45° Both Ends Elbow - SP2K
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 | 6 |
|---|---|---|---|---|---|---|---|
| A (in) | 1.13 | 1.44 | 1.75 | 2.06 | 2.38 | 3.13 | 4.13 |
| R (in) | 1.50 | 2.25 | 3.00 | 3.75 | 4.50 | 6.00 | 9.00 |
Industrial Weld Elbows
90° Butt Weld Elbow - SP2WC
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 | 6 |
|---|---|---|---|---|---|---|---|
| A (in) | 1.50 | 2.25 | 3.00 | 3.75 | 4.50 | 6.00 | 9.00 |
45° Butt Weld Elbow - SP2WK
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 0.625 | 0.938 | 1.25 | 1.56 | 1.88 | 2.50 |
| B (in) | 1.50 | 2.25 | 3.00 | 3.75 | 4.50 | 6.00 |
Bevel Seat Elbows
90° 15 Elbow - 2C
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
90° 13H-14 Elbow - 2E
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
90° 15 x 13H-14 Elbow - 2F
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
Concentric 90° 15 x 13H - 2F-31
Dimensional Data
| Size | 1.5 x 1 | 2 x 1.5 | 2.5 x 2 | 3 x 2 | 3 x 2.5 | 4 x 3 |
|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.88 | 3.72 | 3.72 | 4.84 | 5.91 |
| B (in) | 2.00 | 2.91 | 3.78 | 3.84 | 4.84 | 5.47 |
Eccentric 90° 15 x 13H-14 - 2F-32
Dimensional Data
| Size | 1.5 x 1 | 2 x 1.5 | 2.5 x 2 | 3 x 2 | 3 x 2.5 | 4 x 3 |
|---|---|---|---|---|---|---|
| A (in) | 2.00 | 2.88 | 3.72 | 3.72 | 4.84 | 5.91 |
| B (in) | 2.00 | 2.91 | 3.78 | 3.84 | 4.84 | 5.47 |
45° 15 Elbow - 2K
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 1.31 | 1.72 | 2.13 | 2.63 | 3.13 | 4.25 |
45° 15 x 13H-14 - 2P
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.13 | 2.13 | 2.31 | 2.56 | 2.91 | 3.88 |
| B (in) | 1.31 | 1.72 | 2.13 | 2.63 | 3.13 | 4.25 |
John Perry Elbows
90° 15 Elbow - JP2C
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
90° 13H-14 Elbow - JP2E
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
90° 15 x 13H-14 Elbow - JP2F
Dimensional Data
| Size | 1 | 1.5 | 2 | 2.5 | 3 | 4 |
|---|---|---|---|---|---|---|
| A (in) | 2.18 | 2.97 | 3.72 | 4.59 | 5.41 | 7.03 |
See the fittings catalog for our full selection of stainless steel fittings. Don’t see what you’re looking for? Contact us for additional sizes.
