TrueClean® CIP’able Air Blow Check Valve
The first and only sanitary air blow check valve that can be cleaned in place with a process line. Unlike traditional air blow check valves, the TrueClean® CIP’able air blow check valve can open without performing an air blow.
With the valve open, CIP fluid is able to clean the valve along with the processing line. The simple, compact valve easily fits in place of an existing standard air blow check valve.
Technical Data
Max product/CIP pressure: 150 PSIG
Temperature range: 2—200ºF
Max air pressure to actuator & valve: 125 PSIG
Actuator air input range: 60-125 PSIG
Air blow connection pressure range: 10-125 PSIG
Actuator air inlet size: 1/4” push fit
Air blow coupling inlet size: 3/4” TC
US patent number: 8,602,045
Features & Options
Meets 3-A standards
316L stainless steel construction
Stem seat and O-ring material: Viton or EPDM
Available with 1.5” or 2” Tri-Clamp® connection
