TrueClean® Air Eliminator
Compact and easy to install, the TrueClean® Air Eliminator is an automatic air relief valve that removes entrained air from process lines and prevents product leakage. An internal ball floats when product enters the valve body and creates a seal that prevents outward flow while an o-ring further protects against product leaving the pipeline.
Designed with cleanability in mind, all internal surfaces of the air eliminator are sloped to ensure proper draining.
Technical Data
Max pressure: 145 psi
Max temperature: 194°F
Ball density: 0.033 lbs/in. cubed
Materials
Body: 316L stainless steel
Ball: Polypropylene
O-ring & Gasket: EPDM or Viton
